使用 K8S 或 Docker 快速部署 tensuns 监控告警

2026-01-08
6
0
0
57分钟

写在最前

🦄后羿 - TenSunS(原ConsulManager)：基于Consul的运维平台：更优雅的Consul管理UI&多云与自建ECS/MySQL/Redis同步Prometheus/JumpServer&ECS/MySQL/Redis云监控指标采集&Blackbox站点监控维护&漏洞通知/资源到期余额告警&各类资源Grafana看板展示

安装流程作者在github中已经写得非常详细了，在此我就不记录了，仅记录使用过程中的细节

1. docker 部署

2. kubernetes 部署

2.1 redis-exporter

2.1.1 deployment

kind: Deployment
apiVersion: apps/v1
metadata:
  name: redis-exporter
  namespace: monitoring
  labels:
    app: redis-exporter

  annotations:
    deployment.kubernetes.io/revision: '2'
spec:
  replicas: 1
  selector:
    matchLabels:
      app: redis-exporter

  template:
    metadata:
      creationTimestamp: null
      labels:
        app: redis-exporter
        net_name: net-app-ms

      annotations:
        kubesphere.io/creator: admin
        kubesphere.io/imagepullsecrets: '{"redis-exporter":"harbor-dev"}'
        kubesphere.io/restartedAt: '2024-02-28T08:33:02.488Z'
        logging.kubesphere.io/logsidecar-config: '{}'
    spec:
      volumes:
        - name: host-time
          hostPath:
            path: /etc/localtime
            type: ''
        - name: volume-fky8wd
          secret:
            secretName: redis-exporter-secret
            items:
              - key: redis_passwd.json
                path: redis_passwd.json
            defaultMode: 420
      containers:
        - name: redis-exporter
          image: 'oliver006/redis_exporter:v1.80.1'
          args:
            - '-redis.password-file=/redis_passwd.json'
          ports:
            - name: http-9121
              containerPort: 9121
              protocol: TCP
          env:
            - name: REDIS_EXPORTER_INCL_SYSTEM_METRICS
              value: 'true'
          resources: {}
          volumeMounts:
            - name: host-time
              readOnly: true
              mountPath: /etc/localtime
            - name: volume-fky8wd
              readOnly: true
              mountPath: /redis_passwd.json
              subPath: redis_passwd.json
          livenessProbe:
            httpGet:
              path: /
              port: 9121
              scheme: HTTP
            timeoutSeconds: 1
            periodSeconds: 10
            successThreshold: 1
            failureThreshold: 3
          readinessProbe:
            httpGet:
              path: /
              port: 9121
              scheme: HTTP
            timeoutSeconds: 1
            periodSeconds: 10
            successThreshold: 1
            failureThreshold: 3
          terminationMessagePath: /dev/termination-log
          terminationMessagePolicy: File
          imagePullPolicy: IfNotPresent
      restartPolicy: Always
      terminationGracePeriodSeconds: 30
      dnsPolicy: ClusterFirst
      securityContext: {}
      imagePullSecrets:
        - name: harbor-dev
      schedulerName: default-scheduler
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxUnavailable: 25%
      maxSurge: 25%
  revisionHistoryLimit: 10
  progressDeadlineSeconds: 600

2.1.2 secret

在 Tensuns 中新建实例前，必须预先配置 Redis 实例的连接地址与认证密码，否则实例匹配将无法生效，数据也无法被正确抓取。

{

"redis://app-redis1.default:6379":"123456",

"redis://app-redis2.default:6379":"123456",

"redis://app-redis4.default:6379":"123456",

"redis://app-redis5.default:6379":"123456",

"redis://app-redis6.default:6379":"123456"

}

kind: Secret
apiVersion: v1
metadata:
  name: redis-exporter-secret
  namespace: monitoring
  annotations:
    kubesphere.io/creator: admin
data:
  redis_passwd.json: ?????????????????????
type: Opaque

2.1.3 service

kind: Service
apiVersion: v1
metadata:
  name: redis-exporter
  namespace: monitoring
  labels:
    app: redis-exporter
  annotations:
    kubesphere.io/creator: admin
spec:
  ports:
    - name: http-9121
      protocol: TCP
      port: 9121
      targetPort: 9121
  selector:
    app: redis-exporter
    net_name: net-app-ms
  type: ClusterIP
  sessionAffinity: None
  ipFamilies:
    - IPv4
  ipFamilyPolicy: SingleStack
  internalTrafficPolicy: Cluster

2.1.4 grafana

https://grafana.com/grafana/dashboards/17507-1-redis-exporter-dashboard/

2.2 mysql-exporter

2.2.1 deployment

kind: Deployment
apiVersion: apps/v1
metadata:
  name: mysql-exporter
  namespace: monitoring
  labels:
    app: mysql-exporter
  annotations:
    deployment.kubernetes.io/revision: '1'
    kubesphere.io/creator: admin
    kubesphere.io/description: ''
spec:
  replicas: 1
  selector:
    matchLabels:
      app: mysql-exporter
  template:
    metadata:
      creationTimestamp: null
      labels:
        app: mysql-exporter
        net_name: net-app-ms
      annotations:
        kubesphere.io/creator: admin
    spec:
      volumes:
        - name: host-time
          hostPath:
            path: /etc/localtime
            type: ''
      containers:
        - name: mysql-exporter
          image: 'prom/mysqld-exporter:v0.18.0'
          command:
            - /bin/mysqld_exporter
            - '--collect.binlog_size'
            - '--collect.info_schema.innodb_metrics'
            - '--collect.info_schema.tables'
            - '--collect.info_schema.processlist'
            - '--collect.info_schema.tables.databases=*'
            - '--collect.info_schema.innodb_cmpmem'
            - '--mysqld.username=mon'
          ports:
            - name: http-9104
              containerPort: 9104
              protocol: TCP
          env:
            - name: TZ
              value: Asia/Shanghai
            - name: MYSQLD_EXPORTER_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: mysql-exporter-secret
                  key: MYSQLD_EXPORTER_PASSWORD
          resources: {}
          volumeMounts:
            - name: host-time
              readOnly: true
              mountPath: /etc/localtime
          livenessProbe:
            httpGet:
              path: /
              port: 9104
              scheme: HTTP
            timeoutSeconds: 1
            periodSeconds: 10
            successThreshold: 1
            failureThreshold: 3
          readinessProbe:
            httpGet:
              path: /
              port: 9104
              scheme: HTTP
            timeoutSeconds: 1
            periodSeconds: 10
            successThreshold: 1
            failureThreshold: 3
          startupProbe:
            httpGet:
              path: /
              port: 9104
              scheme: HTTP
            timeoutSeconds: 1
            periodSeconds: 10
            successThreshold: 1
            failureThreshold: 3
          terminationMessagePath: /dev/termination-log
          terminationMessagePolicy: File
          imagePullPolicy: IfNotPresent
      restartPolicy: Always
      terminationGracePeriodSeconds: 30
      dnsPolicy: ClusterFirst
      securityContext: {}
      imagePullSecrets:
        - name: harbor-dev
      schedulerName: default-scheduler
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxUnavailable: 25%
      maxSurge: 25%
  revisionHistoryLimit: 10
  progressDeadlineSeconds: 600

2.2.2 secret

CREATE USER 'mon'@'%' IDENTIFIED BY '?????????????????????' WITH MAX_USER_CONNECTIONS 10;

GRANT PROCESS, REPLICATION CLIENT, SELECT ON . TO 'mon'@'%';

kind: Secret
apiVersion: v1
metadata:
  name: mysql-exporter-secret
  namespace: monitoring
  annotations:
    kubesphere.io/creator: admin
    kubesphere.io/description: ''
data:
  MYSQLD_EXPORTER_PASSWORD: ?????????????????????
type: Opaque

2.2.3 service

kind: Service
apiVersion: v1
metadata:
  name: mysql-exporter
  namespace: monitoring
  labels:
    app: mysql-exporter
  annotations:
    kubesphere.io/creator: admin
spec:
  ports:
    - name: http-9104
      protocol: TCP
      port: 9104
      targetPort: 9104
  selector:
    app: mysql-exporter
    net_name: net-app-ms
  type: ClusterIP
  sessionAffinity: None
  ipFamilies:
    - IPv4
  ipFamilyPolicy: SingleStack
  internalTrafficPolicy: Cluster

2.2.4 grafana

https://grafana.com/grafana/dashboards/17320-1-mysqld-exporter-dashboard/

2.3 blackbox-exporter

2.3.1 deployment

kind: Deployment
apiVersion: apps/v1
metadata:
  name: blackbox-exporter
  namespace: monitoring
  labels:
    app: blackbox-exporter
  annotations:
    deployment.kubernetes.io/revision: '6'
    kubesphere.io/creator: admin
spec:
  replicas: 1
  selector:
    matchLabels:
      app: blackbox-exporter
  template:
    metadata:
      creationTimestamp: null
      labels:
        app: blackbox-exporter
        net_name: net-app-ms
      annotations:
        kubesphere.io/creator: admin
        kubesphere.io/imagepullsecrets: '{"blackbox-exporter":"harbor-dev"}'
        kubesphere.io/restartedAt: '2024-01-24T03:43:46.262Z'
    spec:
      volumes:
        - name: tz-config
          hostPath:
            path: /usr/share/zoneinfo/Asia/Shanghai
            type: ''
        - name: blackbox-config
          configMap:
            name: blackbox-config
            defaultMode: 420
        - name: host-time
          hostPath:
            path: /etc/localtime
            type: ''
      containers:
        - name: blackbox-exporter
          image: 'prom/blackbox-exporter:v0.28.0'
          args:
            - '--config.file=/etc/blackbox/blackbox.yaml'
          ports:
            - name: tcp-9115
              containerPort: 9115
              protocol: TCP
          resources:
            limits:
              cpu: '1'
              memory: 1Gi
            requests:
              cpu: 100m
              memory: 100Mi
          volumeMounts:
            - name: tz-config
              readOnly: true
              mountPath: /etc/localtime
            - name: blackbox-config
              readOnly: true
              mountPath: /etc/blackbox
          terminationMessagePath: /dev/termination-log
          terminationMessagePolicy: File
          imagePullPolicy: IfNotPresent
      restartPolicy: Always
      terminationGracePeriodSeconds: 30
      dnsPolicy: ClusterFirst
      securityContext: {}
      imagePullSecrets:
        - name: harbor-dev
      schedulerName: default-scheduler
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxUnavailable: 25%
      maxSurge: 25%
  revisionHistoryLimit: 10
  progressDeadlineSeconds: 600

2.3.2 configmap

kind: ConfigMap
apiVersion: v1
metadata:
  name: blackbox-config
  namespace: monitoring
  annotations:
    kubesphere.io/creator: admin
data:
  blackbox.yaml: |

    modules:
      http_2xx:
        prober: http
        http:
          valid_status_codes: [200,204]
          no_follow_redirects: false
          preferred_ip_protocol: ip4
          ip_protocol_fallback: false

      # 用于需要检查SSL证书有效性，但是该域名访问后又会重定向到其它域名的情况，这样检查的证书有效期就是重定向后域名的。
      # 如果需要检查源域名信息，需要在blackbox中增加禁止重定向参数。
      httpNoRedirect4ssl:
        prober: http
        http:
          valid_status_codes: [200,204,301,302,303]
          no_follow_redirects: true
          preferred_ip_protocol: ip4
          ip_protocol_fallback: false

      # 用于忽略SSL证书检查的站点监控。
      http200igssl:
        prober: http
        http:
          valid_status_codes:
          - 200
          tls_config:
            insecure_skip_verify: true

      http_4xx:
        prober: http
        http:
          valid_status_codes: [401,403,404]
          preferred_ip_protocol: ip4
          ip_protocol_fallback: false

      http_5xx:
        prober: http
        http:
          valid_status_codes: [500,502]
          preferred_ip_protocol: ip4
          ip_protocol_fallback: false

      http_post_2xx:
        prober: http
        http:
          method: POST

      icmp:
        prober: icmp

      tcp_connect:
        prober: tcp

      ssh_banner:
        prober: tcp
        tcp:
          query_response:
          - expect: "^SSH-2.0-"
          - send: "SSH-2.0-blackbox-ssh-check"

2.3.3 service

kind: Service
apiVersion: v1
metadata:
  name: blackbox-exporter
  namespace: monitoring
  labels:
    app: blackbox-exporter
  annotations:
    kubesphere.io/creator: admin
spec:
  ports:
    - name: http-9115
      protocol: TCP
      port: 9115
      targetPort: 9115
  selector:
    app: blackbox-exporter
    net_name: net-app-ms
  type: ClusterIP
  sessionAffinity: None
  ipFamilies:
    - IPv4
  ipFamilyPolicy: SingleStack
  internalTrafficPolicy: Cluster

2.3.4 grafana

https://grafana.com/grafana/dashboards/9965-1-blackbox-exporter-dashboard-20220412/

2.4 node-exporter

2.4.1 daemonset

kind: DaemonSet
apiVersion: apps/v1
metadata:
  name: node-exporter
  namespace: monitoring
  labels:
    app.kubernetes.io/component: exporter
    app.kubernetes.io/name: node-exporter
    app.kubernetes.io/part-of: kube-prometheus
    app.kubernetes.io/version: 1.3.1
  annotations:
    deprecated.daemonset.template.generation: '1'
spec:
  selector:
    matchLabels:
      app.kubernetes.io/component: exporter
      app.kubernetes.io/name: node-exporter
      app.kubernetes.io/part-of: kube-prometheus
  template:
    metadata:
      creationTimestamp: null
      labels:
        app.kubernetes.io/component: exporter
        app.kubernetes.io/name: node-exporter
        app.kubernetes.io/part-of: kube-prometheus
        app.kubernetes.io/version: 1.3.1
    spec:
      volumes:
        - name: proc
          hostPath:
            path: /proc
            type: ''
        - name: sys
          hostPath:
            path: /sys
            type: ''
        - name: root
          hostPath:
            path: /
            type: ''
      containers:
        - name: node-exporter
          image: 'prom/node-exporter:v1.3.1'
          args:
            - '--web.listen-address=127.0.0.1:9100'
            - '--path.procfs=/host/proc'
            - '--path.sysfs=/host/sys'
            - '--path.rootfs=/host/root'
            - '--no-collector.wifi'
            - '--no-collector.hwmon'
            - >-
              --collector.filesystem.ignored-mount-points=^/(dev|proc|sys|var/lib/docker/.+)($|/)
            - >-
              --collector.filesystem.ignored-fs-types=^(autofs|binfmt_misc|cgroup|configfs|debugfs|devpts|devtmpfs|fusectl|hugetlbfs|mqueue|overlay|proc|procfs|pstore|rpc_pipefs|securityfs|sysfs|tracefs)$
          resources:
            limits:
              cpu: '1'
              memory: 500Mi
            requests:
              cpu: 102m
              memory: 180Mi
          volumeMounts:
            - name: proc
              readOnly: true
              mountPath: /host/proc
            - name: sys
              readOnly: true
              mountPath: /host/sys
            - name: root
              readOnly: true
              mountPath: /host/root
              mountPropagation: HostToContainer
          terminationMessagePath: /dev/termination-log
          terminationMessagePolicy: File
          imagePullPolicy: IfNotPresent
        - name: kube-rbac-proxy
          image: 'kubesphere/kube-rbac-proxy:v0.11.0'
          args:
            - '--logtostderr'
            - '--secure-listen-address=[$(IP)]:9100'
            - >-
              --tls-cipher-suites=TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256,TLS_ECDHE_ECDSA_WITH_AES_128_GCM_SHA256,TLS_RSA_WITH_AES_128_CBC_SHA256,TLS_ECDHE_ECDSA_WITH_AES_128_CBC_SHA256,TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256
            - '--upstream=http://127.0.0.1:9100/'
          ports:
            - name: https
              hostPort: 9100
              containerPort: 9100
              protocol: TCP
          env:
            - name: IP
              valueFrom:
                fieldRef:
                  apiVersion: v1
                  fieldPath: status.podIP
          resources:
            limits:
              cpu: '1'
              memory: 100Mi
            requests:
              cpu: 10m
              memory: 20Mi
          terminationMessagePath: /dev/termination-log
          terminationMessagePolicy: File
          imagePullPolicy: IfNotPresent
          securityContext:
            runAsUser: 65532
            runAsGroup: 65532
            runAsNonRoot: true
      restartPolicy: Always
      terminationGracePeriodSeconds: 30
      dnsPolicy: ClusterFirst
      nodeSelector:
        kubernetes.io/os: linux
      serviceAccountName: node-exporter
      serviceAccount: node-exporter
      hostNetwork: true
      hostPID: true
      securityContext:
        runAsUser: 65534
        runAsNonRoot: true
      affinity:
        nodeAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            nodeSelectorTerms:
              - matchExpressions:
                  - key: node-role.kubernetes.io/edge
                    operator: DoesNotExist
      schedulerName: default-scheduler
      tolerations:
        - operator: Exists
  updateStrategy:
    type: RollingUpdate
    rollingUpdate:
      maxUnavailable: 1
      maxSurge: 0
  revisionHistoryLimit: 10

2.4.2 service

kind: Service
apiVersion: v1
metadata:
  name: node-exporter
  namespace: monitoring
  labels:
    app.kubernetes.io/component: exporter
    app.kubernetes.io/name: node-exporter
    app.kubernetes.io/part-of: kube-prometheus
    app.kubernetes.io/version: 1.3.1
spec:
  ports:
    - name: https
      protocol: TCP
      port: 9100
      targetPort: https
  selector:
    app.kubernetes.io/component: exporter
    app.kubernetes.io/name: node-exporter
    app.kubernetes.io/part-of: kube-prometheus
  clusterIP: None
  clusterIPs:
    - None
  type: ClusterIP
  sessionAffinity: None
  ipFamilies:
    - IPv4
  ipFamilyPolicy: SingleStack
  internalTrafficPolicy: Cluster

2.4.3 grafana

https://grafana.com/grafana/dashboards/8919-node-exporter-dashboard-20240520-tensuns/

2.5 kafka-exporter

2.5.1 deployment

kind: Deployment
apiVersion: apps/v1
metadata:
  name: kafka-exporter
  namespace: monitoring
  labels:
    app: kafka-exporter
    net_name: net-app-ms
  annotations:
    deployment.kubernetes.io/revision: '2'
    kubesphere.io/creator: tanqidi
spec:
  replicas: 1
  selector:
    matchLabels:
      app: kafka-exporter
      net_name: net-app-ms
  template:
    metadata:
      creationTimestamp: null
      labels:
        app: kafka-exporter
        net_name: net-app-ms
      annotations:
        kubesphere.io/creator: admin
        kubesphere.io/imagepullsecrets: '{}'
        kubesphere.io/restartedAt: '2025-06-23T05:54:10.619Z'
    spec:
      volumes:
        - name: tz-config
          hostPath:
            path: /usr/share/zoneinfo/Asia/Shanghai
            type: ''
        - name: host-time
          hostPath:
            path: /etc/localtime
            type: ''
      containers:
        - name: kafka-exporter
          image: 'danielqsj/kafka-exporter:v1.9.0'
          args:
            - '--kafka.server=kafka-0.kafka.default:9092'
            - '--kafka.server=kafka-1.kafka.default:9092'
            - '--kafka.server=kafka-2.kafka.default:9092'
          ports:
            - name: tcp-9308
              containerPort: 9308
              protocol: TCP
          resources:
            requests:
              memory: 100M
          volumeMounts:
            - name: tz-config
              readOnly: true
              mountPath: /etc/localtime
          terminationMessagePath: /dev/termination-log
          terminationMessagePolicy: File
          imagePullPolicy: IfNotPresent
      restartPolicy: Always
      terminationGracePeriodSeconds: 30
      dnsPolicy: ClusterFirst
      securityContext: {}
      affinity: {}
      schedulerName: default-scheduler
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxUnavailable: 25%
      maxSurge: 25%
  revisionHistoryLimit: 10
  progressDeadlineSeconds: 600

2.5.2 service

kind: Service
apiVersion: v1
metadata:
  name: kafka-exporter
  namespace: monitoring
  labels:
    app: kafka-exporter
  annotations:
    kubesphere.io/creator: tanqidi
spec:
  ports:
    - name: http-9308
      protocol: TCP
      port: 9308
      targetPort: 9308
  selector:
    app: kafka-exporter
    net_name: net-app-ms
  type: ClusterIP
  sessionAffinity: None
  ipFamilies:
    - IPv4
  ipFamilyPolicy: SingleStack

2.5.3 grafana

https://grafana.com/grafana/dashboards/7589-kafka-exporter-overview/

写在最后

如果觉得文章对你有用，请随意赞赏

tensuns

使用 K8S 或 Docker 快速部署 tensuns 监控告警

https://tanqidi.com/archives/019b9b55-60fa-74af-8056-6d1729def90a

作者

世界哪有真情在

发布于

2026-01-08

更新于

2026-01-08

许可协议

CC BY 4.0

使用 K8S 或 Docker 快速部署 tensuns 监控告警

写在最前

1. docker 部署

2. kubernetes 部署

2.1 redis-exporter

2.1.1 deployment

2.1.2 secret

2.1.3 service

2.1.4 grafana

2.2 mysql-exporter

2.2.1 deployment

2.2.2 secret

2.2.3 service

2.2.4 grafana

2.3 blackbox-exporter

2.3.1 deployment

2.3.2 configmap

2.3.3 service

2.3.4 grafana

2.4 node-exporter

2.4.1 daemonset

2.4.2 service

2.4.3 grafana

2.5 kafka-exporter

2.5.1 deployment

2.5.2 service

2.5.3 grafana

写在最后

作者

发布于

更新于

许可协议

评论
